Permanent Magnet Suction Cup

TAG :

Doublemagnetic Circuitplatehoisting Chuck

  • Category :Permanent Magnet Suction Cup
  • Casting material :

    Its handle damping foroe is 30%-40% of the single magnetic circuit jack, which is applicable to a wider range

  • Load range :

    Working load limit(WLL)0.1-10T

  • Usage :

    Can be used alone or in combination with other machines to move long and large ferromagnetic materials

  • Note:

    Bottom "Vgroove design, can be suspended steel plate and round steel

Product Details

Product features:


The dual magnetic circuit permanent magnet crane is a series of magnetic circuit products composed of strong magnetic Qiniron boron. The magnetic circuit system is controlled by the rotation of the handle to achieve the working purpose. This product has the characteristics of strong suction, low residual magnetism, light self weight, and reasonable structure. Especially, the damping force of the handle is 30% -40% of that of a single magnetic circuit permanent magnet crane, which has a wider range of applications. It can lift magnetic conductive materials above 5mm, effectively solving the problem of low efficiency in single magnetic circuit permanent magnet lifting of thin plates. The thin plate dual magnetic path permanent magnet crane adopts imported high-performance permanent magnet materials to form a strong magnetic system, which can strongly adsorb the suspended object and achieve a pull-off force of up to 3.5 times.


Adopting fully enclosed welding, it is more dustproof, and the rotating shaft of the permanent magnet suction cup is not easy to get stuck; High performance permanent magnet material with strong suction force and unique magnetic circuit design with almost zero residual magnetism; The bottom "V" groove design can lift corresponding round steel; Passed ISO9001 certification and CE certification, with a one-year warranty.
